11 · Prevalence
There are many ways to keep a durable, consistent store. The previous chapter used an append-only event log.
This approach has some similarities with the prevalence model. One of the most enduring components of the BKNR project is precisely the BKNR datastore, an implementation of the prevalence model using CLOS; since we briefly exemplified event-sourcing, we can compare and contrast how prevalence works - where it differs and where it matches - so that it can be used when it makes sense..
What prevalence means (with BKNR datastore)
CLOS objects live in RAM. They are your working model - directly addressable, directly modifiable with setf.The log is a durability mechanism: on restart, BKNR loads the last snapshot and replays the transaction log to reach current state. You never write a fold; you write ordinary Lisp and let the library handle persistence.
The [BKNR datastore](https://bknr.net/html/software.html) implements this model in Common Lisp. It traces its lineage to the Prevayler project (Klaus Wustefeld, 2001), an early formulation of some concepts that would later be included in event sourcing. One key distinction: what the log *is*. In event sourcing the log is the source of truth. In prevalence the log is infrastructure - a recovery artefact.
Persistent classes and indices
A persistent class is a CLOS class with a metaclass that enforces write discipline. Slots marked :update may only be written inside a logged transaction. Indices are transient and rebuild automatically when the store opens:
(bk:define-persistent-class replicant ()
((designation :read :index-type idx:string-unique-index
:index-reader replicant-with-designation
:index-values all-replicants)
(status :update :initform :at-large
:index-type idx:hash-index
:index-reader replicants-with-status)
(sightings :update :initform 0)))replicant-with-designation is an O(1) hash lookup, not a fold. replicants-with-status returns all objects with a given status value directly from the index. No query language required, nor an ORM..
Transactions
deftransaction defines a function that logs its call (name and arguments) to disk atomically with the in-memory mutation. On crash, any partial write is discarded. On restart, each logged call is re-executed against the live object graph:
(bk:deftransaction retire-replicant (designation)
(let ((r (replicant-with-designation designation)))
(when (and r (eq (replicant-status r) :at-large))
(setf (replicant-status r) :retired))))The log stores commands (function name and arguments), not domain events. This is a critical difference from event sourcing: you are logging what you did, not what happened.
Opening the store
(unless (boundp 'bk:*store*)
(make-instance 'bk:mp-store
:directory "/tmp/rep-detect-store/"
:subsystems (list (make-instance 'bk:store-object-subsystem))))The unless guard makes file-reload in a live SLIME session harmless. On first open, the store directory is created. On subsequent opens, the latest snapshot is loaded and the transaction log replayed.
Comparison with event sourcing
Both models survive process restarts and avoid discarding data on update. A very simplified comparison:
- > Source of truth: event log (ES) vs. live object graph (prevalence).
- > Current state: fold the log on every read / use snapshots/ use projections (ES) vs. read directly from the object slot (prevalence).
- > Log role: primary store (ES) vs. crash recovery artefact (prevalence).
- > Reads: build a projection (ES) vs. index lookup (prevalence).
- > Time travel: replay any prefix of the log (ES) vs. restore-store up to a timestamp, less ergonomic (prevalence).
- > Audit: events are domain facts with clear semantics (ES) vs. commands are operations that should be replayed (prevalence).
If the log itself is a business artefact - financials, compliance, audit trails, frequent temporal queries - event sourcing is likely preferred. If your domain is naturally object-oriented, reads are varied and frequent, and the log is infrastructure rather than the model, prefer prevalence - but only when it fits in RAM, which is a very important consideration.
Live demo
A live deployment of the Replicant Registry runs at rep-detect.lambda-combine.net. It demonstrates persistent state across server restarts, concurrent modification with conflict detection, and the BKNR transaction model in a real application.
Full Source (standalone BKNR)
This is a simplified version of the Replicant Detector
Load with sbcl --load prevalence.lisp (requires bknr.datastore via Quicklisp). State persists to /tmp/prevalence-store/ and survives restarts.
The source uses the keyed registry introduced in chapter 10: reg:make-keyed-sse-registry for broadcast plus per-session unicast (reg:notify-subscriber).
;;;; -*- Mode: LISP; fill-column: 80; coding: utf-8 -*-
;;;; PREVALENCE.LISP --- Blade Runner replicant registry (BKNR datastore)
;;;;
;;;; Copyright (C) 2025, 2026 Frederico Muñoz / ΛↃ lambda combine
;;;;
;;;; This file is part of datastar-cl, the Common Lisp SDK for Datastar
;;;;
;;;; License: MIT
;;; Demonstrates the prevalence model using BKNR Datastore. Read alongside
;;; event-sourcing.lisp (#11), which models the same write/query/push pattern
;;; with an event log instead.
;;;
;;; WHAT IS PREVALENCE?
;;;
;;; The prevalence model (Prevayler, Klaus Wüstefeld, 2001) keeps the entire
;;; domain in RAM, here (using BKNR datastore, inspired by Prevayler and similar
;;; libraries) as live CLOS objects, logs every mutation (a "transaction") to
;;; disk atomically, and periodically saves a full snapshot. On restart, load
;;; the latest snapshot, then replay the transaction log to reach the current
;;; state. The same overall recovery mechanism as event sourcing, but the
;;; *emphasis* is different.
;;;
;;; Prevalence:
;;; - Objects are long-lived, mutable, and their current state is what matters.
;;; - You need indexed reads across many objects (no fold required).
;;; - You want persistence without a separate DB process.
;;; - The domain is well-understood and schema evolution is manageable.
;;; Event sourcing:
;;; - The history itself is a first-class business artefact (audit, compliance).
;;; - Multiple independent read models need to project the same event stream.
;;; - Temporal queries ("what was the state on date X?") are frequent.
;;;
;;; PERSISTENCE DEMO:
;;; 1. Start the server, mutate state (sight, retire, spawn).
;;; 2. Ctrl-C, then: sbcl --load prevalence.lisp
;;; State survives: registry loaded from /tmp/prevalence-store/.
;;; The seed block does NOT re-run (objects present, guard fires).
;;; To snapshot manually in the REPL: (bknr.datastore:snapshot)
;;;
;;; Run with: sbcl --load prevalence.lisp
;;;
;;; SYSTEM DEFINITION ;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
(ql:quickload '(:hunchentoot :spinneret :bordeaux-threads
:datastar-cl/hunchentoot :datastar-cl/registry :bknr.datastore))
(defpackage #:prevalence
(:use #:cl #:hunchentoot)
(:local-nicknames (:sp :spinneret)
(:d* :datastar-cl)
(:reg :datastar-cl.registry)
(:bt :bordeaux-threads)
(:ht :hunchentoot)
(:bk :bknr.datastore)
(:idx :bknr.indices)))
(in-package #:prevalence)
;;; PERSISTENT CLASS: objects are the model; slots are mutable state ;;;;;;;;;;
;;;
;;; DEFINE-PERSISTENT-CLASS is DEFCLASS with (:metaclass persistent-class).
;;; Slot option :READ generates a reader; :UPDATE generates a reader + writer.
;;; The metaclass enforces that :UPDATE slot writes only happen inside a logged
;;; transaction: an attempt outside raises a SIMPLE-ERROR.
;;;
;;; Indices are *transient* and rebuild automatically on every store open/restore.
;;; STRING-UNIQUE-INDEX uses EQUAL as hash-test (string-aware).
;;; HASH-INDEX uses EQL, right for keyword values like :AT-LARGE, :RETIRED.
(bk:define-persistent-class replicant ()
((designation :read :index-type idx:string-unique-index
:index-reader replicant-with-designation
:index-values all-replicants)
(model :read) ; string, distinct values below
(role :read)
(incept :read)
(status :update :initform :at-large
:index-type idx:hash-index
:index-reader replicants-with-status
:index-keys all-statuses)
(sightings :update :initform 0)
(last-seen :update :initform nil)))
;;; TRANSACTIONS: must be defined BEFORE the store is opened ;;;;;;;;;;;;;;;;;
;;;
;;; DEFTRANSACTION defines NAME (public: logs + executes) and TX-NAME (the
;;; implementation, called only inside a transaction context). The log stores
;;; the function symbol and its arguments, it's not a domain event, but a
;;; command. On restore, each logged call is re-executed against the live object
;;; graph.
;;;
;;; Critical ordering: make-instance 'mp-store immediately replays the
;;; transaction log. TX-SPAWN-REPLICANT etc. must exist before that call or the
;;; restore will signal UNDEFINED-FUNCTION.
(bk:deftransaction spawn-replicant (designation model role incept)
(make-instance 'replicant :designation designation :model model
:role role :incept incept))
(bk:deftransaction sight-replicant (designation)
(let ((r (replicant-with-designation designation)))
(when r
(incf (replicant-sightings r))
(setf (replicant-last-seen r) (get-universal-time)))))
(bk:deftransaction retire-replicant (designation)
(let ((r (replicant-with-designation designation)))
(when (and r (eq (replicant-status r) :at-large))
(setf (replicant-status r) :retired))))
;;; STORE: single global instance, idempotent on reload ;;;;;;;;;;;;;;;;;;;;;;;;;
;;;
;;; make-instance 'mp-store opens (or restores) the store and binds *store*.
;;; The UNLESS guard makes file-reload in a live SLIME session harmless.
(defparameter *store-dir* "/tmp/prevalence-store/")
(unless (boundp 'bk:*store*)
(make-instance 'bk:mp-store :directory *store-dir*
:subsystems (list (make-instance 'bk:store-object-subsystem))))
;;; RENDERING ;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;; Make it pretty. Extracted from the LASS version of the house style and copied
(defparameter *css*
"body{background:#0a0803;color:#ffb000;font-family:'Cousine','Courier New',monospace;
margin:0;padding:40px 20px;display:flex;justify-content:center}
body::before{content:'';position:fixed;inset:0;
background:linear-gradient(rgba(18,16,16,0) 50%,rgba(0,0,0,.25) 50%);
background-size:100% 3px;pointer-events:none;z-index:100}
.terminal{max-width:1000px;width:100%;border:1px solid #996a00;padding:30px;
box-shadow:0 0 15px rgba(255,176,0,.15)}
h1{font-family:'Saira Extra Condensed','Saira Semi Condensed','Courier New',monospace;
display:grid;grid-template-columns:auto 1fr;column-gap:.6rem;font-size:2rem;
margin:0 0 5px;text-transform:uppercase;font-weight:500;
border-bottom:1px dashed #996a00;padding-bottom:10px}
.acronym{font-family:'DejaVu Sans',sans-serif;font-size:3.6rem;font-weight:700;
color:#ffcc00;line-height:.9;letter-spacing:-11px;margin-right:10px}
.wordmark{font-family:'Saira Extra Condensed','Courier New',monospace;
display:flex;flex-direction:column;justify-content:center;
line-height:.73;letter-spacing:12px}
.combine{letter-spacing:9px}
.meta{color:#a87d00;font-size:.85rem;text-transform:uppercase;letter-spacing:1px;margin:.3em 0}
h2{font-family:'Saira Extra Condensed','Courier New',monospace;font-size:1.5rem;
text-transform:uppercase;letter-spacing:2px;margin:1em 0 .3em;color:#ffcc00}
table{border-collapse:collapse;width:100%;margin:.5em 0}
th{color:#ffcc00;border-bottom:1px solid #996a00;padding:.3em .6em;
text-align:left;text-transform:uppercase;letter-spacing:1px}
td{padding:.2em .6em;border-bottom:1px solid #1a1000}
.at-large{color:#ffb000}.retired td{color:#664d00}
.stats{color:#f89d00;font-size:.85rem;text-transform:uppercase;letter-spacing:1px;margin:.5em 0;padding:1rem}
button{background:transparent;border:1px solid #996a00;color:#ffb000;font-family:inherit;
font-size:.65rem;padding:4px 12px;cursor:pointer;
letter-spacing:1px;text-transform:uppercase;margin-right:.3em}
button:hover{background:#ffb000;color:#0a0803}
input,select{background:transparent;border:1px solid #996a00;color:#ffb000;
font-family:inherit;font-size:.85rem;padding:4px 8px;margin-right:.3em}
input:focus,select:focus{outline:none;border-color:#ffb000}
.footer{margin-top:20px;padding-top:10px;border-top:1px dashed #996a00;
color:#a87d00;font-size:.72rem;letter-spacing:1px;text-transform:uppercase}
.msg{color:#ff4400;min-height:1.2em;margin:.3em 0}
.processing{color:#ffb000;min-height:1.2em;margin:.3em 0;
letter-spacing:1px;animation:blink 1s steps(2) infinite}
@keyframes blink{50%{opacity:.3}}
hr{border:none;border-top:1px dashed #996a00;margin:1em 0}")
(defun fmt-time (ut)
(when ut
(multiple-value-bind (s m h) (decode-universal-time ut)
(format nil "~2,'0d:~2,'0d:~2,'0d" h m s))))
(defun render-stats ()
;; Indexed O(1) reads. Compare to event-sourcing.lisp's balance-from which
;; must reduce the whole log to answer this question. Of course, there are
;; others ways of doing it there as well, so this is not an "advantage" in
;; general, but specific to the implementation here
(let ((at-large (length (replicants-with-status :at-large)))
(retired (length (replicants-with-status :retired)))
(models (remove-duplicates
(mapcar #'replicant-model (all-replicants)) :test #'equal)))
(format nil "AT-LARGE: ~D | RETIRED: ~D | MODELS: ~{~A~^, ~}"
at-large retired models)))
(defun render-registry ()
(sp:with-html-string
(:div :id "registry"
(:p :class "stats" (:raw (render-stats)))
(:table
(:thead
(:tr (:th "DESIGNATION") (:th "MODEL") (:th "ROLE")
(:th "INCEPT") (:th "STATUS") (:th "SIGHTINGS")
(:th "LAST SEEN") (:th "")))
(:tbody
(dolist (r (all-replicants))
(let ((desig (replicant-designation r))
(class (string-downcase (symbol-name (replicant-status r)))))
(:tr :class class
(:td desig)
(:td (replicant-model r))
(:td (replicant-role r))
(:td (replicant-incept r))
(:td (symbol-name (replicant-status r)))
(:td (replicant-sightings r))
(:td (or (fmt-time (replicant-last-seen r)) "-"))
(:td (:button :|data-on:click|
(format nil "$target='~A'; ~A"
desig (d*:sse-post "/sight"))
"SIGHT")
(when (eq (replicant-status r) :at-large)
(:button :|data-on:click|
(format nil "$target='~A'; ~A"
desig (d*:sse-post "/retire"))
:|data-indicator:processing| ""
"RETIRE")))))))))))
(defun push-registry (gen)
(d*:patch-elements gen (render-registry) :selector "#registry"))
;;; SUBSCRIPTION (CQRS push layer) ;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;;;
;;; *CLIENTS* is a keyed registry: NOTIFY-SUBSCRIBERS broadcasts to all
;;; connected generators; NOTIFY-SUBSCRIBER + sid key targets one.
;;; The sid is a UUID assigned by the browser at page load (crypto.randomUUID)
;;; and carried on every request as a Datastar signal.
(defvar *clients* (reg:make-keyed-sse-registry "prevalence"))
(defvar *server* nil)
(defparameter *command-delay* 5
"Seconds RETIRE is held before processing. Creates a staleness window in which
a concurrent RETIRE from another tab will conflict. (setf *command-delay* 0) to disable.")
(defun broadcast ()
(reg:notify-subscribers *clients* #'push-registry))
;;; REPLY-TO delivers the command outcome asynchronously to one client over its
;;; already-open SSE stream; empty MSG string clears a previous warning.
(defun reply-to (sid &optional (msg ""))
(reg:notify-subscriber *clients* sid
(lambda (g) (d*:patch-signals g (list :msg msg)))))
;;; HANDLERS ;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
(ht:define-easy-handler (index :uri "/") ()
(setf (ht:content-type*) "text/html")
(sp:with-html-string
(:doctype)
(:html
(:head (:meta :charset "UTF-8")
(:link :rel "stylesheet"
:href "https://fonts.googleapis.com/css2?family=Cousine:ital,wght@0,400;0,700;1,400;1,700&family=Saira+Extra+Condensed:wght@400;500;700&family=Saira+Semi+Condensed:wght@400&display=swap")
(:link :rel "stylesheet"
:href "https://fonts.cdnfonts.com/css/dejavu-sans?styles=253,247")
(:script :type "module" :src (d*:datastar-url))
(:style (:raw *css*)))
(:body :data-signals (d*:init-signals :designation "" :model "Nexus-6"
:role "" :incept "" :target "" :msg "" :sid ""
:processing nil)
:data-init (format nil "$sid = crypto.randomUUID(); ~A" (d*:sse-get "/sse"))
(:div :class "terminal"
(:h1 (:span :class "acronym" "ΛↃ")
(:span :class "wordmark"
(:span "LAMBDA")
(:span :class "combine" "COMBINE")))
(:p :class "meta"
"Integrated Tracking Systems Division -- "
"REP-DETECT Terminal v.2019")
(:h2 "Replicant Registration Database")
(:p :class "meta"
"LAPD Blade Runner Division -- Tyrell Corp. Subcontract LC-2018-BR")
(:raw (render-registry))
(:hr)
(:p (:strong "REPORT UNREGISTERED UNIT: ")
(:input :type "text" :placeholder "Designation" :data-bind "designation"
:style "width:10em" :maxlength 10)
(:select :data-bind "model"
(:option :value "Nexus-6" "Nexus-6")
(:option :value "Nexus-7" "Nexus-7")
(:option :value "Nexus-8" "Nexus-8"))
(:input :type "text" :placeholder "Role" :data-bind "role"
:style "width:8em" :maxlength 10)
(:input :type "text" :placeholder "Incept" :data-bind "incept"
:style "width:8em" :maxlength 10)
(:button :|data-on:click| (d*:sse-post "/spawn") "SPAWN"))
(:p :class "processing" :data-show "$processing" :style "display:none"
"> TRANSMITTING RETIREMENT ORDER TO CENTRAL...")
(:p :class "msg" :data-show "$msg != ''" :style "display:none"
:data-text "$msg")
(:div :class "footer"
"ΛↃ Lambda Combine · Integrated Tracking Systems ·"
"Persistent prevalence store: " *store-dir*))))))
;;; Pure-push SSE: empty body, :keep-alive drives heartbeat. :on-connect pushes
;;; current registry before registering so the first render is immediate (not
;;; waiting for the next broadcast). The sid from the browser's
;;; crypto.randomUUID() is registered so POST handlers can unicast replies back
;;; to exactly this client.
(ht:define-easy-handler (sse-handler :uri "/sse") ()
(d*:with-signals ((sid "sid" "")) ht:*request*
(d*:with-sse (gen ht:*request*
:on-connect (lambda (g) (push-registry g) (reg:register *clients* g :key sid))
:on-disconnect (lambda (g) (reg:unregister *clients* g))
:keep-alive t))))
;;; Command endpoints: fire-and-forget (204 No Content).
;;;
;;; Commands return immediately; outcomes arrive over the push channel:
;;; * success: broadcast new registry to all subscribers;
;;; unicast empty $msg to requester to clear any previous warning.
;;; * rejection: unicast rejection message to requester's stream only.
;;;
;;; RETIRE sleeps *COMMAND-DELAY* seconds before processing: this opens a
;;; staleness window so a second operator acting on the stale view can issue a
;;; conflicting RETIRE. RETIRE then checks the transaction's return value,
;;; non-NIL only if THIS call actually performed the retire, and warns the
;;; requester if it lost the race. SPAWN and SIGHT are additive and run
;;; immediately.
(ht:define-easy-handler (spawn-handler :uri "/spawn") ()
(d*:with-signals ((desig "designation" "") (model "model" "Nexus-6")
(role "role" "") (incept "incept" "")
(sid "sid" "")) ht:*request*
(cond ((zerop (length desig)) (reply-to sid "Designation required"))
((replicant-with-designation desig)
(reply-to sid "Designation already registered"))
(t (spawn-replicant desig model role incept) (broadcast) (reply-to sid))))
(setf (ht:return-code*) ht:+http-no-content+)
"")
;; We do not check if it's on a retired unit. Maybe it wasn't retired...
(ht:define-easy-handler (sight-handler :uri "/sight") ()
(d*:with-signals ((target "target" "") (sid "sid" "")) ht:*request*
(when (plusp (length target))
(sight-replicant target) ; additive, no conflict possible
(broadcast)
(reply-to sid))) ; clear any prior warning
(setf (ht:return-code*) ht:+http-no-content+)
"")
;; We actually block here, and wait for the answer; this way we can use
;; data-indicator directly.
(ht:define-easy-handler (retire-handler :uri "/retire") ()
(d*:with-signals ((target "target" "") (sid "sid" "")) ht:*request*
(when (plusp (length target))
(sleep *command-delay*) ; another operator may retire it in this window
(cond ((string= target "N7FAB00001") ; Rachael can't be retired, an
; example of a "business rule"
(reply-to sid
(format nil "~A retirement order failed -- system error code RACH32fa00a139"
target)))
((retire-replicant target) ; non-nil only if THIS call performed the retire
(broadcast) (reply-to sid))
(t (reply-to sid
(format nil "~A was already retired by another unit -- command void"
target))))))
(setf (ht:return-code*) ht:+http-no-content+)
"")
;;; SEED: only when the store is empty (skipped on restart, which is the point)
(when (null (all-replicants))
(spawn-replicant "N6MAA10816" "Nexus-6" "Combat" "2016-01-08") ; Roy Batty
(spawn-replicant "N6FAB21416" "Nexus-6" "Pleasure" "2016-02-14") ; Pris
(spawn-replicant "N6MAC41717" "Nexus-6" "Loader" "2017-04-10") ; Leon
(spawn-replicant "N7FAB00001" "Nexus-7" "Experimental" "--")) ; Rachael
;;; STARTUP ;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;;;
;;; START-SERVER is non-blocking: Hunchentoot serves on its own background
;;; threads, so calling it leaves a live server and a usable REPL prompt.
;;;
;;; MAIN is the entry point for a saved executable. It starts the server then
;;; parks the main thread; without the parking loop the image would exit the
;;; moment the toplevel function returned. Defining MAIN is inert for REPL
;;; use; only the top-level (start-server) call below runs at load time.
;;;
;;; Top-level forms do NOT re-run when a dumped image boots, only MAIN does.
(defun start-server (&key (port 8989))
(when *server* (ht:stop *server*))
(setf *server* (make-instance 'ht:easy-acceptor :port port))
(ht:start *server*)
(format t "~&REP-DETECT terminal online, http://localhost:~D~%" port)
(format t "~&Store: ~A | Replicants on file: ~D~%"
*store-dir* (length (all-replicants)))
(format t "~&To snapshot: (bknr.datastore:snapshot)~%")
*server*)
(defun main ()
"Entry point for SAVE-LISP-AND-DIE :toplevel; starts the server and parks."
(start-server)
(handler-case (loop (sleep 60)) ; park; serving happens on bg threads
(#+sbcl sb-sys:interactive-interrupt
#-sbcl error ()
(when *server* (ht:stop *server*)))))
;; REPL / `sbcl --load` convenience, start now and return.
(start-server)
(defroute guide-prevalence (:get :text/html))
